22000mAh capacity (~488Wh) for maximum endurance on heavy-lift missions
In stock
Batteries Power
Tattu 22000mAh 6S 25C LiPo (heavy-lift)
The Tattu (Gens Ace) 22000mAh 6S 25C is a large-format lithium-polymer pack built for the most demanding heavy-lift drone applications.
₹33,499 + 18% GST
SKU: BOTBIT-BATT-05 · Best for: Heavy-lift octocopter and large hexacopter platforms
Overview
About Tattu 22000mAh 6S 25C LiPo (heavy-lift).
The Tattu (Gens Ace) 22000mAh 6S 25C is a large-format lithium-polymer pack built for the most demanding heavy-lift drone applications. With six cells in series at 22.2V nominal and a 22000mAh capacity, it stores roughly 488Wh of energy, delivering extended endurance for industrial multirotors carrying heavy payloads over long missions.
Its 25C continuous rating (50C burst) is higher than typical agricultural packs, so it can feed large motors with the strong current heavy octocopters demand while still offering a high energy density of around 185Wh/kg. As a Tattu Plus smart battery, it includes status indication, storage and self-discharge management, and an intelligent storage mode that holds cells at an optimal voltage when idle. Premium Japanese and Korean polymer cells and heavy AWG8 wiring with an AS150+XT150 connector complete the professional-grade build.
This pack is aimed at commercial operators running heavy-lift cinematography rigs, large survey and LiDAR platforms, and industrial inspection drones that need both long flight time and robust current delivery. It is a premium choice for users whose missions justify a large, high-energy battery built for repeated professional service.
Key features
Why it stands out.
25C continuous (50C burst) delivers strong current for large octocopter motors
High ~185Wh/kg energy density balances flight time against pack weight
Smart Tattu Plus features: status indication and intelligent storage mode
AS150+XT150 connector with AWG8 wiring for demanding professional power draw
Specifications
Selection facts.
| Chemistry | LiPo (lithium polymer) |
|---|---|
| Capacity | 22000mAh |
| Configuration | 6S1P (6 cells) |
| Nominal voltage | 22.2V |
| Energy | ~488 Wh |
| Continuous discharge | 25C |
| Max burst discharge | 50C |
| Energy density | ~185 Wh/kg |
| Discharge connector | AS150 + XT150 |
| Wire gauge | AWG8 |
| Weight | ~2650 g (±20 g) |
| Dimensions | 213 x 96 x 69 mm |
Applications
Where it is used.
- Heavy-lift octocopter and large hexacopter platforms
- Industrial LiDAR and survey mapping drones
- Professional aerial cinematography rigs
- Long-endurance inspection and monitoring drones
- Agricultural and utility drones with large payloads
- Research and development heavy-lift airframes
Buying guide
How to choose.
Choose this pack when your mission needs both long endurance and strong current: the 22000mAh capacity gives extended flight time, while the 25C continuous rating supports heavy octocopters and demanding payloads. Verify your aircraft can physically accept the 213 x 96 x 69 mm pack and roughly 2.65 kg of weight, and that the power harness matches the AS150+XT150 connector.
As a smart Tattu Plus battery, it adds status indication and an intelligent storage mode that helps maintain cell health between deployments, which is valuable for fleets in regular commercial use. Pair it with a charger rated for large 6S packs, charge at a safe rate, and rotate packs so each can rest and cool, preserving cycle life across heavy duty cycles.
For Indian commercial operators, plan for the transport and storage requirements of large LiPo packs, which are restricted on passenger air cargo and typically moved by specialised surface logistics. Keep packs in a cool, ventilated, fire-safe area, store at storage voltage when idle, and inspect cells and connectors before every flight to maintain safe, reliable operation.
FAQ
Common questions.
What sets the 22000mAh 25C apart from the 16000mAh 15C?
It offers both more capacity (22000mAh versus 16000mAh) and a higher 25C continuous discharge rating versus 15C. That means longer flight time and stronger current delivery, making it suited to larger, more demanding heavy-lift platforms, at the cost of more weight and a higher price.
How much energy does this pack store?
At 22.2V nominal and 22000mAh, it stores roughly 488Wh of energy, with an energy density around 185Wh/kg. That high energy figure is what enables the extended endurance heavy-lift and industrial drone missions require.
What connector and wiring does it use?
The pack uses a high-current AS150 plus XT150 discharge connector with heavy AWG8 wiring, matched to the large current draw of heavy-lift platforms. Confirm your aircraft's power system uses the same connector or fit an adapter rated for the continuous current.
What are the smart battery features?
As a Tattu Plus pack it includes battery status indication, storage and self-discharge management, and an intelligent storage mode that holds cells at an optimal voltage when idle. These features help maintain cell health and are useful for commercial fleets in regular service.
How heavy is it and will it fit my drone?
It weighs about 2650 g and measures roughly 213 x 96 x 69 mm. Because that is a substantial size and weight, confirm your airframe's battery tray and payload budget can accommodate it, and recalculate all-up weight and expected flight time accordingly.
How do I store and maintain it safely?
Use the intelligent storage mode or charge to storage voltage when idle, keep the pack cool and in a fire-safe area, and inspect cells and connectors before each flight. Rotate multiple packs to let them rest, charge at a safe rate, and track cycle counts to replace packs before performance degrades.
